Saettia mk2

Inshore Patrol Vessels

inshore Patrol

These ships enable coast guards to upgrade their institutional activities of patrolling and safeguarding national waters. High operational flexibility enables operations to be carried out in many different roles such as patrolling blue waters, anti pollution operations, assisting other craft in difficulty, search and rescue operations. Such vessels have a length of 50÷55 metres and can reach a maximum speed ranging from 23 up to above 30 knots as a function of the chosen propulsion system.

Commissioning  Italian Navy
Ubaldo Diciotti 2002
Luigi Dattilo 2002
Michele Fiorillo 2003
Michele Fiorillo 2003
Orazio Corsi 2003

Technical Information

main characteristics

Length overall

52.80 m

Length between perpendiculars

47.20 m

Moulded breadth

8.10 m

Moulded depth

5.40 m

Full load displacement

427 t

Corresponding moulded draught

2.26 m

Trial load displacement

392 t

Corresponding moulded draught

2.26 m

Max speed

31 kn

Range at 16 kn

over 1,800 nm

Endurance

up to 7 days

Rudders

2

Propellers

4 controllable pitch

Bow thruster

1

Service craft

2 RHIBs

Machine gun

1 x 20 ÷ 30 mm

VERTREP capability

CREW

Total

29 people

ENERGY AND PROPULSION SYSTEM

Diesel engines

4 (I.F. V1716T2 MSD - 2360 kW each)

Diesel generators

3 (I.F. L1306T2ME– 208 kW each)

Emergency generator

1
