Kalaat Beni-Abbes
Amphibious Ship
San Giusto Class
The Kalaat Beni-Abbes is a landing platform dock (LPD) ship, developed as a technological enhancement of the Italian "San Giusto" amphibious class vessel and retaining and perfecting some of the latter’s most significant features. The most important of these is the presence of an internal floodable dock, capable of accommodating a ready-to-go chaland (a 20-metre landing craft); the other two landing craft of the same size can travel attached to the ship's deck, and can be deployed using a system of davits. If necessary, the dock can be emptied to accommodate other types of vehicles.
| Commissioning | Algerian Navy |
| KALAAT BENI-ABBES | 2014 |
Technical Information
main characteristics
Length overall
142.90 m
Length between perpendiculars
127.60 m
Breadth
21.50 m
Depth to flight deck
16.20 m
Depth to garage deck
7.70 m
Full load displacement
abt. 8,800 t
Main diesel engines
2 x 6,000 kW
Maximum speed
20 kn
Range at 15 kn
7,000 nm
Crew
152 people
Transported
438 + 12 people
HELO CAPABILITIES
Flight Deck
• 2 landing spots for EH101
• 2 take-off for EH101 & Super Lynx-type helicopters
Hangar
recovery of Super Lynx helicopters type
Hangar/Garage deck
up to 465 m (garage + fore area of flight deck)
Hospital area
abt. 250 m²
Floodable dock
dimensions abt. 20.50 x 7 m
Vehicle ramps
1 stern + 1 side
combat system
1 Combat Management System
1 Identification Friend or Foe Phased Array + Transponder
2 X-Band Navigation Radars
1 Navigation System
1 Helo Deck Radar
1 Fire Control System
1 Electronic Warfare System
1 Anti-Air Warfare Decoy Launching System (2 launchers)
1 76/62 SR Main Gun
2 25 mm Machine Guns
1 Ship to Air Missile (1 x 8 + 1 x 8 fitted for) + Multifunctional Radar
1 Integrated Communication System
