DATTILO class

Offshore Patrol Vessels

Dattilo

The main mission of Offshore Patrol Vessels is to safeguard national interests through patrolling activities and carry out anti-pollution and rescue services. The aft area is often fitted with a flight deck for the take-off and landing operations of one mediumsized helicopter. Typical features of such vessels are the extensive range as well as sea-keeping and manoeuvrability performances, which make them highly flexible from the operational point of view.

Technical Information

main characteristics

Length overall

94.50 m

Length between perpendiculars

80.00 m

Moulded breadth

16.60 m

Max breadth

20.50 m

Design depth

8.50 m

Full load displacement

abt. 3,600 t

Cruising speed

abt. 13 kn

Max continuous speed

17 kn

Range at 13 kn

abt. 3,000 nm

Complement/technicians

20 + 30 people

Rescued

60 people

ENERGY AND PROPULSION SYSTEM

Propulsion system CODLOD with n.2 electric motors

Main engines

2 x GE 12V228 2 289 kW

OTHER CAPABILITIES

Flight deck for AB412 or AW139

Dynamic Positioning DP1

N.4 high speed RHIBs

N.2 deck crane

N.1 loading ramp for wheeled vehicles

Additional class notations: OIL RECOVERY CLASS, FIRE FIGHTING CLASS, RESCUE CLASS
